The Motor Control Center (MCC) at the well site supplies power and controls low-voltage AC motors, lighting systems, living facilities, and other AC equipment.
MCC， It refers to the control device for the electric drive of drilling rig auxiliary machinery, which realizes the centralized and remote control operation of equipment, solves the difficulties caused by the dispersion of electrical equipment in installation, maintenance, inspection and management, and is conducive to the overall explosion prevention of the control device.
The above equipment and its supporting explosion-proof circuit can meet the working parameters, performance, and drilling process requirements of various drilling rigs, and also have explosion-proof, waterproof, fireproof, anti-corrosion, and impact resistant properties, which can adapt to the harsh conditions of outdoor operations in oil fields.
Technical Specifications:
| Model
| DYFB-400V/380V-AC1250KW |
| Rated power
| 2500A |
| Input voltage
| AC380V |
| Output voltage
| Three phase five wire AC380V，single-phase AC220V |
| Leakage action time
| ≤0.1S |
| Leakage circuit breaker resistor
| ≤0.2MΩ |
| Ambient temperature
| -15℃～50℃ |
| Altitude
| ≤2000m |
| Dielectric strength
| The 1000V megohmmeter measures not less than 2M Ω
|
| Detecting ground leakage current
| AC0.04-0.12mA |
| Alarm sound
| ≤100dB |
| Transformer insulation grade
| H Class |
| System grounding form
| IT approach
|
| Corrosion resistance grade | WF1 |
The above and other safety electrical products can be customized according to the actual situation
