Adopting 380V input, microcomputer real-time online insulation monitoring technology, and terminal data acquisition and uploading, to ensure the safety of all electricity consumption in the villa. The power can be customized by oneself.
Technical Specifications:
| Model
| DYFB-380V/220V-12KW |
| Rated power
| 54.5A |
| Input voltage
| AC380V |
| Output voltage
| Three phase five wire AC380V，single-phase AC220V |
| Leakage action time
| ≤0.1S |
| Leakage circuit breaker resistor
| ≤0.2MΩ |
| Ambient temperature
| -15℃～50℃ |
| Altitude
| ≤2000m |
| Dielectric strength
| The 1000V megohmmeter measures not less than 2M Ω
|
| Detecting ground leakage current
| AC0.04-0.12mA |
| Alarm sound | ≤100dB |
| Transformer insulation grade
| H Class |
| System grounding form
| IT approach |
| Corrosion resistance grade
| WF1 |
The above and other safety electrical products can be customized according to the actual situation
